XTER Series High-Temperature Resistant Wire for aviation

XTER Series High-Temperature Resistant Wire for aviation

Overview
The conductor of this product is composed of monofilament 0.08mm silver-plated copper core, which has good flexibility, and the insulation and jacket are made of fluorine material, which has excellent electrical insulation and high and low temperature resistance, and can be used for a long time within the range of -65℃-+250℃. The products are impact resistant, crack resistant, chemically stable and resistant to acid, alkali, oil and other solvents. The product is soft, easy to peel off the head, widely used in electrical equipment and instrumentation line connection in high temperature, low temperature ,requiring the product to be soft and other special environmental conditions.

Execution standard
O/XT 20019-2022 Detailed specification of XTER series high-performance transmission line

Characteristics
Temperature range:-65℃-+250℃:
Rated voltage:AC600V for XTER1 series:
Minimum bending radius:8 times of the cable’s outer diameter:
Solderability:Silver-plated conductor has solderability.

Type and Specification

Cable Basic Constructure
