XLPE power cable for offshore oil platform 3.6/6 to 18/30kV is intended for power transmission of various ships,offshore oil platform and offshore building.
Application:
XLPE power cable for offshore oil platform 3.6/6 to 18/30kV is intended for power transmission of various ships, offshore oil platform and offshore building.
Marking:
Insulation shall be recognized by colored tape and comply with the stipulation of GBT6995.5. lt is allowwed, in necessary, to use other methods.
The sheath color is red and printed with manufactures name, type, specification, voltage, length, etc
Service Property Parameter：
| Main Parameter | Performance Index |
|---|
| Rated Voltage | 3.6/6 ~ 18/30kV |
| Max Operating Temperature | 90℃ |
| Minimum Bending Radius | Single-core Cable≥12D ; Three-core Cable≥9D (D: cable diameter, mm) |
| A.C. Voltage Test | 3.5U0/5min without puncture |
| Partial discharge capacity under 1.73U0 test voltage | ≤ 10pC |
Executive Standard：
| Design | IEC 60092-354 |
| Conductor | IEC 60228 |
| Insulation | IEC 60092-351 |
| Sheath | IEC 60092-359 |
| Flame Retardant | EC 60332-3-22 |
| Halogen Free | IEC 60754 |
| Low Smoke | IEC 61034 |
Type & Description：
| Type | Description |
|---|
| CJP/SC | XLPE insulated thermoplastic PO sheathed offshore oil platform power cable, SC type |
| CJP80/SC | XLPE insulated thermoplastic PO inner sheathed bare tinned copper wire braided armor offshore oil platform power cable, SC type |
| CJP90/SC | XLPE insulated thermoplastic PO inner sheathed bare steel wire braided armor offshore oil platform power cable, SC type |
| CJP86/SC | XLPE insulated thermoplastic PO inner sheathed tinned copper wire braided armor thermoplastic PO outer sheathed offshore oil platform power cable, SC type |
| CJP96/SC | XLPE insulated thermoplastic PO inner sheathed steel wire braided armor thermoplastic PO outer sheathedoffshore oil platform power cable, SC type |
| CJPJ/SC | XLPE insulated XLPO sheathed offshore oil platform power cable, SC type |
| CJPJ80/SC | XLPE insulated XLPO inner sheathed bare tinned copper wire braided armor offshore oil platform power cable, SC type |
| CJPJ90/SC | XLPE insulated XLPO inner sheathed bare steel wire braided armor ofishore ail platform power cable, SC type |
| CJPJ85/SC | XLPE insulated XLPO inner sheathed tinned copper wire braided armor XLPO outer sheathed offshore oil platform power cable, SC type |
| CJPJ95/SC | XLPE insulated XLPO inner sheathed steel wire braided armor XLPO outer sheathed offshore oil platform power cable, SC type |
Type Comparison：
| Type for oil platform | Type of our company |
|---|
| HOFR | CJP86/SC；CJP96/SC；CJPJ85/SC；CJPJ95/SC |
