Silicon Rubber insulated silicone rubber sheathed shipboard power cable SA type
Silicone rubber insulated silicone rubber sheathed shipboard power cable, SA type, available to metallurgical, chemical, power plant and mining
Application:
The cable is intended for electric power, lighting and general control system of shipboard, oil platform and offshore building etc,lt is also available to metallurgical industry, chemical works, power plant and mining enterprises etc.
Marking:
Insulated core shall identified by color or figure and comply with the stipulations of GB/6995.5-2008.
The sheath color is black and printed with manufacture name, manufacture year, type, specifications, voltage and length etc.
Service Property Parameter：
| Main Parameter | Performance Index |
|---|---|
| Rated Voltage | 0.6/1kV |
| Max Operating Temperature | 95℃ |
| Minimum Bending Radius | ≥6D (D: cable diameter, mm) |
| A.C. Voltage Test | 3.5kV/5min without puncture |
Executive Standard：
| Design | IEC 60092-353 |
| Conductor | IEC 60228 |
| Insulation | IEC 60092-351 |
| Sheath | IEC 60092-359 |
| Flame Retardant | IEC 60332-3-22 |
| Halogen Free | IEC 60754 |
| Low Smoke | IEC 61034 |
Type & Description：
| Type | Description |
|---|---|
| CSS/SA | Silicone rubber insulated silicone rubber sheathed shipboard power cable, SA type |
| CSSR/SA | Silicone rubber insulated silicone rubber sheathed flexible shipboard power cable, SA type |
| CSPJ/SC | Silicone rubber insulated XLPO(SHF2) sheathed low-smoke halogen-free flame-retardant shipboardpower cable.SC type |
| CSPJR/SC | Silicone rubber insulated XLPO(SHF2)sheathed low-smoke halogen-free flame-retardant flexibleshipboard power cable, SC type |
