Low temperature, Middle temperature, High temperature series automatic-control-temperature heating cable

Low temperature, Middle temperature, High temperature series automatic-control-temperature heating cable

LOW TEMPERATURE SERIES

Application:
The automatic-control-temperature heating cable is that of a special one adjusting automatically the power accordance with thetemperature change.t has two functions: automatic heating and automatic control temperature. The key part of the automatic confrotemperature heating cable, the automatic-control-temperature conductive core, is imported product, whose stability of temperafurecontrol and time length ofusing is better than the same kid of product at home.

Application:
1. Standard colour. black and blue
2. Temperature scope: maximum maintaining temperature should be 65℃;, maximum surface temperature should be 70’cmaximum admissible operating temperature should be 105℃.
3.Construction temperature: minimum temperature should be -40 ℃
4. The stability of heating: on and off for 1000 times during 22 days in succession, over 90% of the heat can bemaintaines.
5. Bending radius: 12.7mm for 20℃ room temperature, 35.0mm for -30’℃ low temperature.
6. Insulation resistance: should be not less than 100lM() between conductor and shield, when use 2500VDC swinging instrumentfor one minute under the ambient temperature 75
7.Operating voltage:12V,24V,36V 110V 220V.380V
8.The output power at 10℃:10,15.25.45W/m.

Structure diagram

MIDDLE TEMPERATURE SERIES
Application:
ZKWD series of automatic-control electricity-heating cables specifcally used for process lead-out needing blowing intermitentlywith high temperature, process pipeline or container tank’s preeze-proof, thermastat and part heating, its maximum maintainingtemperature is 105℃, and it is available in the ordinary area, dangerous area and corrosive area
1. Standard colour: brown, saffron and black
2. Temperature scope. maximum maintaining temperature should be 105’C:; maximum surface temperature should be 105cmaximum admissible operating temperature should be 135C.
3.Constrction temperature: minimum temperature should be -30℃.
4. The stability of heating: on and off for 1000 times during 22 days in succession, over 90% of the heat can bemaintaines5. Bending radius: 12.7mm for 20℃ room temperature, 35.0mm for -30℃ low temperature.
6. Insulation resistance: should be not less than 100M( between conductor and shield, when use 2500VDC swinging instrumentfor one minute under the ambient temperature 75℃.
7.Operating voltage:12V 24V36V110V 220V 380V
8. The output power at 10℃:25,35,45,55,60W/m

Structure diagram

HIGH TEMPERATURE SERIES
Application:
ZKWD series of automatic-control electricity-heating cables specifcally used for process leadout needing blowing intermitentlywith high temperature(maximum temperature to 215’c, 30min), process pipeline or container tank’s preeze-proof, thermastat and partheating, its maximum maintaining temperature is 135’c, and it is available in the ordinary area, dangerous area and corosive area.

Main technical index
1.Standard colour: brown, saffon and black.
2. Temperature scope: maximum maintaining temperature should be 105’C, maximum surface temperature should be 105’Cmaximum admissible operatig temperature should be 135C.
3 Construction temperature: lowest temperature should be -30℃
4. The stability of heating: on and off for 1000 times during 22 days in succession, over 90% of the heat can bemaintaines.
5. Bending radius: 12.7mm for 20℃ room temperature, 50.8mm for -30℃ low temperature.
6. Insulation resistance: should be not less than 100M( betwveen conductor and shield, when use 2500VDC swinging instrumentfor one minute under the ambient temperature 75?C
7 perating voltage:12V 24V 36V 110V220V 380V8.The output power at 10℃:25.35.45,55.65,75W/m

Structure Diagram
