Low-smoke halogen-free flame-retardant telecommunication cable light thin-walled for naval ships, transmission, control systems in telecommunication, etc.
Application:
Low-smoke halogen-free flame-retardant telecommunication cable light thin-walled is intended for transmission and control systems in telecommunication, computer and information
processing units on naval ships.
Marking:
Insulation shall be recognized by colored tape and comply with the stipulation of GJB1916.
The sheath color is red and printed with manufactures name, manufactures year, type, specifications, voltage, length, etc.
Service Property Parameter：
| Main Parameter |
Performance Index |
| Rated Voltage |
300V |
| Max Operating Temperature |
90℃ |
| Minimum Bending Radius |
≥6D (D: cable diameter, mm) |
| A.C. Voltage Test |
1.5kV/5min without puncture |
Executive Standard：
| Design |
GJB1916 |
| Design |
MIL-DTL-24643 |
| Design |
IEC 60092-376 |
| Fire Resistant |
IEC 60331 |
| Flame Retardant |
IEC 60332-3-22 |
| Halogen Free |
IEC 60754 |
| Low Smoke |
IEC 61034 |
Type & Description：
| Type |
Description |
| JHR85/SC |
XLPE insulated tinned copper wire braided armor XLPO sheathed low-smoke halogen-free flame-retardant telecommunication flexible cable for naval ship, SC type |
| JHRP85/SC |
XLPE insulated individual shielded tinned copper wire braided armor XLPO sheathed low-smoke halogen-free flame-retardant telecommunication flexible cable for naval ship, SC type |
| JHRPJ/SC |
XLPE insulated XLPO sheathed low-smoke halogen-free flame-retardant telecommunication flexible cable for naval ship, SC type |
