EPR Insulated Shipboard Control Cable 150/250V
EPR Insulated Shipboard Control Cable 150/250V for electric power, lighting, general control system of shipboard, oil platform and offshore
Application:
EPR Insulated Shipboard Control Cable 150/250V is intended for electric power, lighting and general control system of shipboard, oil platform and offshore building, etc.
Marking:
Insulated core shall identified by color or figure and comply with the stipulations of GB/T6995.4-2008.
The sheath color is black and printed with manufacture name, manufacture year, type, specifications, voltage and length etc.
Service Property Parameter：
| Main Parameter | Performance Index |
|---|---|
| Rated Voltage | 150/250V |
| Max Operating Temperature | 90℃ |
| Min Bending Radius | ≥6D (D: cable diameter, mm) |
| A.C. Voltage Test | 1.5kV/5min without puncture |
Executive Standard：
| Design | IEC 60092-376 |
| Conductor | IEC 60228 |
| Insulation | IEC 60092-351 |
| Sheath | IEC 60092-359 |
| Flame Retardant | IEC 60332-3-22 |
| Halogen Free | IEC 60754 |
| Low Smoke | IEC 61034 |
More Products：
| Type | Description |
|---|---|
| CKEF/DA or SA | EPR insulated PCP sheathed shipboard control cable, DA or SA type |
| CKEH/DA or SA | EPR insulated CSP sheathed shipboard control cable, DA or SA type |
| CKEV/DA or SA | EPR insulated PVC sheathed shipboard control cable, DA or SA type |
| CKEP/SC | EPR insulated PO(SHF1) sheathed low-smoke halogen-free flame-retardant shipboard controcable, SC type |
| CKEPJ/SC | EPR insulated Cross-linked XLPO(SHF2) sheathed low-smoke halogen-free flame-retardant shipboardcontral cable, SC type |
| CKEF80/DA or SA | EPR insulated PCP inner sheathed tinned copper wire braided shipboard control cable, DA or SA type |
| CKEH80/DA or SA | EPR insulated CSP inner sheathed tinned copper wire braided shipboard control cable, DA or SA type |
| CKEV80/DA or SA | EPR insulated PVC inner sheathed tinned copper wire braided shipboard control cable, DA or SA type |
| CKEF90/DA or SA | EPR insulated PCP inner sheathed galvanized steel wire braided shipboard control cable, DA or SA type |
| CKEH90/DA or SA | EPR insulated CSP inner sheathed galvanized steel wire braided shipboard control cable, DA or SA type |
| CKEV90/DA or SA | EPR insulated PvC inner sheathed galvanized steel wire braided shipboard control cable, DA or SA type |
| CKEP80/SC | EPR insulated PO(SHF1) inner sheathed tinned copper wire braided low-smoke halogen-free flame.retardant shipboard control cable, SC type |
| CKEP90/SC | EPR insulated PO(SHF1) inner sheathed galvanized steel wire braided low-smoke halogen-free flame-retardant shipboard control cable, SC type |
| CKEPJ80/SC | EPR insulated cross-linked XLPO(SHF2) inner sheathed tinned copper wire braided low-smoke halogen-free flame-retardant shipboard control cable, SC type |
| CKEPJ90/SC | EPR insulated cross--linked XLPO(SHF2) inner sheathed galvanized steel wire braided low-smoke halogen-free flame-retardant shipboard control cable, SC type |
| CKE82/DA or SA | EPR insulated tinned copper wire braided PVC outer sheathed shipboard control cable, DA or SA type |
| CKE86/SC | EPR insulated tinned copper wire braided PO(SHF1) outer sheathed low-smoke halogen-free flame-retardant shipboard control cable, SC type |
| CKE85/SC | EPR insulated tinned copper wire braided cross-linked XLPO(SHF2) outer sheathed low-smoke halogen-free flame-retardant shipboard control cable, SC type |
| CKEF82/DA or SA | EPR insulated PCP inner sheathed tinned copper wire braided PVC outer sheathed shipboard control cable, DA or SA type |
| CKEH82/DA or SA | EPR insulated CSP inner sheathed tinned copper wire braided PVC outer sheathed shipboard control cable, DA or SA type |
| CKEV82/DA or SA | EPR insulated PvC inner sheathed tinned copper wire braided PVC outer sheathed shipboard control cable, DA or SA type |
| CKEF92/DA or SA | EPR insulated PCP inner sheathed galvanized steel wire braided PVC outer sheathed shipboard control cable, DA or SA type |
| CKEH92/DA or SA | EPR insulated CSP inner sheathed galvanized steel wire braided PVC outer sheathed shipboard control cable, DA or SA type |
| CKEV92/DA or SA | EPR insulated PVC inner sheathed galvanized steel wire braided PVC outer sheathed shipboard control cable, DA or SA type |
| CKEP86/SC | EPR insulated PO(SHF1) inner sheathed tinned copper wire braided PO(SHF1) outer sheathed low-smoke halogen-free flame-retardant shipboard control cable, SC type |
| CKEP96/SC | EPR insulated PO(SHF1) inner sheathed galvanized steel wire braided PO(SHF1) outer sheathed low-smoke halogen-free flame-retardant shipboard control cable, SC type |
| CKEPJ85/SC | EPR insulated cross--linked XLPO(SHF2) inner sheathed tinned copper wire braided cross-linked XLPO(SHF2) outer sheathed low-smoke halogen-free flame-retardant shipboard control cable, SC type |
| CKEPJ95/SC | EPR insulated cross-linked XLPO(SHF2) inner sheathed aalvanized steel wire braided cross-linked XLPO(SHF2) outer sheathed low-smoke halogen-free flame-retardant shipboard control cable, SC type |
