Degaussing cable for degaussing station or the degaussing system in degaussing ships

Application

The cable is intended for degaussing stations or the degaussing systems of degaussing ships. The structure andmaterial comply with CB1157 with the properties of oil resistance, abrasion resistance, sea water proof flexible and goodelectrical performance etc.

Executive standard

CB 1157
IEC 60092-353
IEC 60092-351
IEC 60092-359
IEC 60332-3-22

Marking

Insulated core shall identified by figure,The sheath color is black and printed with manufacturename, manufacturing year ,manuiacture year, type,specifications, voltage andlength etc.

Service property parameter

Main parameter Performance index
Rated voltage 0.6/1(1.2)KV
The ambient temperature is from-2 to+32℃, and permited to operating in the sea and fresh water.
long time permissible maximum operating temperature 90℃

The cable can endure water pressure 4.41MPa and two hours crosswise seal test.

Type and description

TYPE	CoresNO.XSection	strands/Dia.MM	OuterDia. Nominal	Outer Dia. Max.	Cable Weight kg/km
DESHR	1X70	999/0.30	22.5	24.5	1030
	1X95	1344/0.30	24.2	27	1321
	1X120	1702/0.30	27.1	29	1609
	1X150	2109/0.30	29.7	32	1974
	1X185	2623/0.30	32.6	35	2405
	1X240	1891/0.40	36.5	40	3065
