Aramid Fiber strength signal cable for naval ships

Aramid Fiber strength signal cable for naval ships

Application
The cable is intended for special signal and lighting device of submarine. High quality aramid fiber material is used asstrength core instead of traditional tightwire with the properties of small diameter, light weight, flexible and good electricalperformance etc.

 Executive standard
GJB1916
IEC 60092-376
IEC 60092-351
IEC 60092-359
IEC 60332-3-22

Marking
Insulated core shall identified by figure,The sheath color is black and printed with manufacturename, manufacturing year ,manuiacture year, type,specifications, voltage andlength etc.
Service propertyparameter

Main parameter                                                                                                                 Performance index
Rated voltage                                                                                                                     AC250V,DC500V
The ambient temperature is from-40 to+50℃, and permited to operating in the sea.
long time permissible maximum operating temperature                                           90℃
The  cable can endure water pressure 4.41MPa and two hours crosswise seal test.
Cable sapping force                                                                                                            ≥ 10000N

Type and description
